EOTech

EOTech EXPS3

Holographic weapon sight with night vision compatibility and quick detach mount

Quick Specs

Price
$749
Weight
11.2 oz
Brand
EOTech
Category
optic

Features

  • Holographic reticle
  • Night vision compatible
  • Quick detach lever
  • Waterproof to 33ft

Capability Boosts

CQB+3
Low Light+2
Reliability+1

Compatibility Tags

interface: picatinny-topsuitable-for: ultra-compact

Overview

The EOTech EXPS3 represents the pinnacle of holographic weapon sight technology, combining the company's legendary quick-acquisition reticle with night vision compatibility and professional-grade construction. Unlike traditional red dots that project an LED onto the lens, EOTech's true holographic technology creates a reticle suspended in the target plane, eliminating parallax and providing unlimited eye relief—even when shooting from unconventional positions.

The iconic 68 MOA ring with 1 MOA center dot enables instant target acquisition at close quarters while the small center dot provides precision for longer engagements. The ring also serves as a ranging tool: when a human-sized target fills the ring from top to bottom, that target is at approximately 100 yards. With 20 daylight brightness settings and 10 night vision compatible settings, the EXPS3 performs in any lighting condition. The side-mounted buttons and shorter profile accommodate magnifiers and flip-to-side mounts perfectly.

Submersible to 33 feet and rated for extreme temperatures, the EXPS3 features a quick-detach lever mount for tool-free installation and return-to-zero capability. The transversely mounted CR123 battery provides approximately 1,000 hours of runtime and can be replaced without removing the sight. Built in the USA, every EXPS3 undergoes rigorous testing to meet military specifications. For operators requiring the fastest possible target acquisition and night vision capability, the EXPS3 remains the professional's choice.

Key Features

  • True holographic reticle eliminates parallax at any eye position
  • 68 MOA ring / 1 MOA dot for speed and precision
  • 30 brightness settings (20 daylight + 10 NVD compatible)
  • Quick-detach lever mount with return-to-zero capability
  • Side-mounted buttons for magnifier compatibility
  • Submersible to 33 feet (10 meters)
  • Transverse CR123 battery for tool-less replacement

Pros

  • +Fastest target acquisition among non-magnified optics
  • +True holographic reticle works better for users with astigmatism
  • +Excellent night vision compatibility across all gen levels
  • +Large viewing window provides superior situational awareness
  • +Side buttons and short profile perfect for magnifier use

Cons

  • 600-1000 hour battery life significantly shorter than LED red dots
  • Premium pricing around $675+ positions above many alternatives
  • 11.2 oz weight notably heavier than micro red dots
  • Requires CR123 batteries (less common than CR2032)

Detailed Specifications

Reticle
68 MOA ring / 1 MOA center dot
Magnification
1x
Battery Type
CR123A
Battery Life
~600 hours (setting 12), 1000+ hours (nominal)
nightVisionCompatible
Yes (10 dedicated NVD settings)
Waterproof Rating
33 feet / 10 meters
weight
11.2 oz
dimensions
3.5 x 2.4 x 2.8 inches
Adjustment Type
0.5 MOA per click
Adjustment Range
±40 MOA windage/elevation
operatingTemp
-40°F to 140°F
Mount Type
Integral QD lever (lower 1/3 co-witness)
