Rifle ChassisPremium

Daniel Defense

Daniel Defense Pro Chassis System (Remington 700)

The Delta 5 Pro chassis architecture cut for the Remington 700 short-action footprint, with an integral RRS and Area 419 spec ARCA lock.

Quick Specs

Price
$1,221
Weight
5 lb 3.2 oz
Brand
Daniel Defense
Category
rifle-chassis

Features

  • Remington 700 action footprint
  • Integral RRS/Area 419-spec ARCA lock
  • 5.2 lb
  • AICS short-action magazines
  • 13.6 to 14.9 in length of pull

Compatibility Tags

family: bolt-actionuse: prsfootprint: rem700interface: arcahandguard: mlokmagazine: aicsplatform: aero-solus-competition-rifleplatform: bergara-b14-hmrplatform: bergara-b14-ridgeplatform: bergara-b14-hunterplatform: custom-precision-rifle

Overview

This is the same chassis architecture Daniel Defense ships on the Delta 5 Pro, machined instead for the Remington 700 action footprint, so it drops onto a 700 or any of the clone actions that copy its inlet and screw spacing. The 6061-T6 aluminum base beds the action metal-on-metal, which keeps the bedding surface stable across temperature and humidity swings. The forend runs an integral ARCA lock cut to both RRS and Area 419 spec along its full lower length, with M-LOK at six positions and one more under the buttstock, and a machined barrier stop that clears the magazine. A scalloped cut at the receiver drops the scope height over bore for large objectives. Ergonomics are adjustable rather than fixed: the thumb rest slides left and right, the grip is an AR-15 interface, and comb height, yaw, drift, length of pull, and butt pad height all adjust without tools. Length of pull spans 13.6 to 14.9 inches, and it feeds any AICS short-action magazine.

Key Features

  • CNC-machined 6061-T6 aluminum base with metal-on-metal mechanical bedding
  • Integral ARCA lock cut to RRS and Area 419 spec along the full lower forend
  • M-LOK at six forend positions plus one on the buttstock underside
  • Ten QD sling swivel attachment points
  • AR-15 grip interface and a left/right adjustable thumb rest
  • Toolless length of pull and butt pad height adjustment, 13.6 to 14.9 in
  • Black Type III hard coat anodize, Coyote Tan Cerakote, or Olive Drab Cerakote

Pros

  • +Integral full-length ARCA cut to both RRS and Area 419 spec
  • +Drops the Delta 5 Pro's competition ergonomics onto a common 700 footprint
  • +Toolless comb and length-of-pull adjustment

Cons

  • Right handed and non-folding, with folding requiring the separate stock adapter
  • 5.2 lb is heavy next to a hunting stock
  • AICS short-action magazines only, so long-action chamberings are out

Detailed Specifications

actionFit
Remington 700 action footprint
weight
5.2 lb
Length
34.48 in
lengthOfPull
13.6 to 14.9 in
magazineCompatibility
Any AICS short-action magazine
Material
CNC-machined 6061-T6 aluminum with glass-infused polymer grip and comb
rail
Integral RRS and Area 419 spec ARCA lock with M-LOK at six forend positions
handedness
Right handed
foldingStock
Non-folding
