Daniel Defense Pro Chassis System (Delta 5)

Drop-in aluminum chassis that puts the Delta 5 Pro forend, integral ARCA lock, and adjustable buttstock on a polymer-stocked Delta 5.

Affiliate links (?)

Check Best Price

View at Daniel Defense

Add to Build

Quick Specs

Price: $1,221
Weight: 5 lb 3.2 oz
Brand: Daniel Defense
Category: rifle-chassis

Features

•Delta 5 action only
•Integral RRS-spec ARCA lock
•5.2 lb
•AICS short-action magazines
•13.6 to 14.9 in length of pull

Compatibility Tags

family: bolt-actionuse: prsinterface: arcahandguard: mlokmagazine: aicsplatform: daniel-defense-delta-5

Overview

Daniel Defense cuts this chassis for its own Delta 5 action rather than a 700 footprint, so it is a drop-in swap for the factory polymer stock on a Delta 5 and nothing else. The base is CNC machined from 6061-T6 aluminum and mechanically beds the action metal-on-metal, which keeps the bedding surface from moving with humidity the way a polymer stock can. The forend carries M-LOK at six positions and a continuous RRS-spec ARCA lock along its entire lower edge, so bipods, tripod clamps, and barrier stops slide anywhere along the rail rather than snapping to fixed points. A scalloped cut at the receiver lets a large-objective scope sit lower over the bore. The grip is an AR-15 interface, so aftermarket grips fit, and the thumb rest adjusts left and right. Length of pull runs 13.6 to 14.9 inches and the comb adjusts for height, yaw, and drift without tools. It feeds any AICS short-action magazine.

Key Features

CNC-machined 6061-T6 aluminum base with metal-on-metal mechanical bedding
Integral RRS-spec ARCA lock running the full lower length of the forend
M-LOK at six forend positions plus one on the buttstock underside
Ten QD sling swivel attachment points
AR-15 grip interface and a left/right adjustable thumb rest
Toolless length of pull and butt pad height adjustment, 13.6 to 14.9 in
Black Type III hard coat anodize, Coyote Tan Cerakote, or Olive Drab Cerakote

Pros

+Turns a polymer-stock Delta 5 into the Pro's chassis configuration without buying a second rifle
+Full-length ARCA is integral rather than a bolted-on rail
+Toolless comb and length-of-pull adjustment

Cons

−Delta 5 actions only, with no 700-pattern fitment
−Right-handed and non-folding, with folding requiring the separate stock adapter
−5.2 lb chassis is heavier than the polymer stock it replaces

Detailed Specifications

actionFit: Daniel Defense Delta 5 action only; Daniel Defense states the mini-chassis will not accommodate 700-pattern actions
weight: 5.2 lb
Length: 34 in
lengthOfPull: 13.6 to 14.9 in
magazineCompatibility: Any AICS short-action magazine
Material: CNC-machined 6061-T6 aluminum with glass-infused polymer grip and comb
rail: Integral RRS-spec ARCA lock with M-LOK at six forend positions
handedness: Right handed
foldingStock: Non-folding
