Reptilia AGS Optic Mount

Symmetric one-piece precision mount at a 1.34" centerline, offered in 0 or 20 MOA. Lower and lighter than the AUS, with no accessory wings.

Quick Specs

Price
$350
Weight
N/A
Brand
Reptilia
Category
optic-mount

Features

  • 1.34" optical centerline
  • 0 MOA or 20 MOA cant
  • 30mm, 34mm, and 35mm ring diameters
  • 148 g billet 7075-T6

Compatibility Tags

rail: picatinnytube: 30mmtube: 34mmtube: 35mm

Overview

The Reptilia AGS is the company's precision-rifle mount, sitting below its AUS carbine mount in height and beside it in construction. It holds the optic at a 1.34 inch centerline over the rail, which is roughly two tenths of an inch lower than the 1.54 inch AUS and low enough that a fixed-comb bolt gun can still reach the eyepiece without a cheek riser.

The body is symmetric and non-cantilever: both rings sit over the mounting surface rather than reaching forward of it, so the load stays centered on the receiver rail instead of hanging off the front of it. Reptilia machines it from billet 7075-T6 aluminum, finishes it in MIL-STD Type III hardcoat anodize, and lands the whole assembly at 148 grams.

Buyers pick 0 MOA or 20 MOA of forward cant along with a 30mm, 34mm, or 35mm ring diameter, which is elevation the AUS line does not offer. The 20 MOA option tilts the optic nose-down so the scope's internal elevation travel is biased toward the top of its range, which is what a rifle dialing past roughly 600 yards needs. It attaches with a spring-loaded nitrided steel clamp and flush-fit hardware onto any M1913 Picatinny rail, and it is made in the USA.

Key Features

  • 1.34 inch optical centerline over the rail
  • 0 MOA or 20 MOA of built-in forward cant
  • 30mm, 34mm, and 35mm ring diameters
  • Symmetric, non-cantilever one-piece body
  • Billet 7075-T6 aluminum, MIL-STD Type III hardcoat anodize
  • 148 grams
  • Spring-loaded nitrided steel clamp with flush-fit hardware
  • M1913 Picatinny rail interface
  • Made in the USA

Pros

  • +Lower and lighter than the Reptilia AUS at the same build quality
  • +20 MOA option buys back scope elevation for long-range dialing
  • +Symmetric body keeps the optic load centered over the receiver
  • +Covers 30mm, 34mm, and 35mm tubes from one product family

Cons

  • No accessory wings for offset red dots, unlike the AUS
  • 1.34 inch height sits below the 1.54 inch lower-1/3 AR co-witness standard
  • Not quick-detach
  • Costs more than the taller AUS mount it sits beside

Detailed Specifications

Mount Type
One-piece symmetric precision scope mount
height
1.34" optical centerline
cant
0 MOA or 20 MOA
tubeDiameter
30mm, 34mm, or 35mm
Material
Billet 7075-T6 aluminum
Finish
MIL-STD Type III hardcoat anodize
weight
148 g (approx. 5.2 oz)
attachment
Spring-loaded nitrided steel Picatinny clamp
madeIn
USA
